Roată de transport Blickle HTH 85X100/20-104K

Bracket: LH series

• strong pressed steel, zinc-plated, blue-passivated, Cr6-free
• heavy fork and top plate
• double ball bearing in the swivel head
• bolted and secured central kingpin, extremely strong
• particularly resistant to shocks and impact due to four specially-shaped, hardened bearing seats

Wheel: G series

• rugged grey cast iron, hardness 180–220 HB, grease nipple, lacquered, colour silver

Other features:

• chemical resistance to many aggressive substances
• operating temperature: -20 °C to +120 °C
• consider the surface pressure on sensitive floors due to high point loads
• provide adequate lubrication on a regular basis for plain bore version
• to be lubricated according to the application temperature
